Parameter

SM

MM

Insertion Loss

≤0.3dB

≤0.2dB

≤0.3dB

≤0.2dB

Return Loss

≥45dB

≥45dB

≥45dB

≥35dB

Mating Durability(1000times)

Additonal Loss≤0.1dB

Reture Loss Variability＜5dB

Temperature Stability(-40℃~85℃)

Additonal Loss≤0.2dB

Reture Loss Variability＜5dB

Operating Temperature

-40~+75

Storage Temperature(℃)

-40~+85

Features:
Low insertion loss value
High-precision sleeve
MTRJ Adapter
Excellent mechanical capability
Stable capability and high reliability

Applications:
Optical test equipment
  Local area network
  Wide area network
  Data processing network
